Descriptio

SUPERPEG 600 / 600 S / 600 W, is a chemical additive for concrete composed of specially selected modified sulfonate raw materials, the

Domaine

• product offers qualities of super plasticizer water reducing at the high rate serving to strengthen the resistance.

• In all ready-mixed concrete classes described in EN 206 and EN 13515.

• Concrete applications with low water/cement ratio.

• Waterproof concrete applications

• Smooth surface applications such as bridges, viaducts Construction of all building elements

Features

• Super plasticizing concrete additive SUPERPEG 600 / 600 S / 600 W allows implementation without creating segregation on fresh concrete.

• It makes it possible to achieve concrete mix designs with low water/cement ratios.

• It increases the resistance of hardened concrete to environmental impact conditions.

• Does not contain chloride ions. It does not cause corrosion of the reinforcements.

• It offers long-term consistency protection functionality to fresh concrete. In this way, the fresh concrete mixture can be transported over long distances.

Utilisatio

• SUPERPEG 600 / 600 S / 600 W is available in liquid form for fresh concrete. It is recommended to join it in the mixing water at the concrete production plant.

Use according to weather conditions

• SUPERPEG 600 S in summer

• SUPERPEG 600 W in winter

• SUPERPEG 600 during the transition period

Standards

• SUPERPEG 600 S: EN 934-2 Table 11.1,11.2 ASTM C 494 Type G

• SUPERPEG 600 W: EN 934-2 Table 3.1, 3.2 ASTM C 494 Type F

• SUPERPEG 600: EN 934-2 Table 3.1, 3.2 ASTM C 494 Type F

Quantity of use

mixing in a range of 0.5% to 2% by weight for all concrete grades described in EN 206 and EN 13515. This ratio varies depending on the cement, aggregate, mineral additive, water components used in the design of concrete mixtures, as well as the desired properties of fresh and hardened concrete. Therefore, laboratory tests should be performed based on the expected properties of fresh concrete and hardened concrete before the utilization rate is determined and the mixing ratio should be determined based on these experiments.

Storage conditions and

The product should be stored above 5 °C. In case of freezing, the product must be mechanically mixed carefully after thawing. Available in 25 kg barrels, 200 kg barrels, 1,000 kg IBC tanks and bulk.

Compatibility

SUPERPEG 600/ 600 S / 600 W is compatible with PLASTPEG, Airpeg,Antipeg,Retardpeg, Proofpeg, Specialpeg from PEGASUS. The PEGASUS Technical Support Unit should be contacted for information on compliance with other additives. If more than one additive is to be used in the desired mixture design, each additive must be added separately to the mixture. SUPERPEG 600 / 600 S / 600 W can be used with all types of cement according to EN 197-1 and with all types of mineral additives (fly ash, blast furnace slag, silica fume, etc.) in accordance with EN 206 and EN 13515.For use in special types of cement, it is recommended to call on PEGASUS technical support.

Precaution of use

Avoid contact of the product with the eyes or skin, in case of contact with them, rinse thoroughly with water. In case of contact with the eyes, wash immediately and thoroughly with water and then consult a specialist. Use gloves, a protective mask and goggles during use. For more information, refer to the product’s Safety Data Sheet (MSDS).
